H05V-K / H07V-K Single Core
Flexible class-5 PVC single core — the workhorse for panel wiring.
Application
Where H05V-K / H07V-K Single Core is used
Internal wiring of appliances, switch and control cabinets, and flexible connections at up to 70°C — rated 300/500 V (H05V-K) and 450/750 V (H07V-K).
- ✓Flexible class-5 copper conductor
- ✓PVC insulated, 70°C rated
- ✓CE / VDE / BS standard
- ✓300/500 V and 450/750 V ratings
Part Numbers & Dimensions
Full technical reference
All figures are from our current production datasheet. Contact us for the signed PDF version for procurement.
H05V-K — 300/500 V
| Nominal Area (mm²) | Structure (mm) | Insulation Thickness (mm) | Nominal Diameter (mm) | Max Diameter (mm) |
|---|---|---|---|---|
| 0.5 | 16/0.2 | 0.6 | 2.12 | 2.6 |
| 0.5 | 28/0.15 | 0.6 | 2.12 | 2.6 |
| 0.75 | 24/0.2 | 0.6 | 2.33 | 2.8 |
| 0.75 | 42/0.15 | 0.6 | 2.33 | 2.8 |
| 1.0 | 32/0.2 | 0.6 | 2.50 | 3.0 |
H07V-K — 450/750 V
| Nominal Area (mm²) | Structure (mm) | Insulation Thickness (mm) | Nominal Diameter (mm) | Max Diameter (mm) |
|---|---|---|---|---|
| 1.5 | 48/0.2 | 0.7 | 3.00 | 3.5 |
| 1.5 | 30/0.25 | 0.7 | 3.00 | 3.5 |
| 2.5 | 49/0.25 | 0.8 | 3.62 | 4.2 |
| 2.5 | 77/0.2 | 0.8 | 3.62 | 4.2 |
| 4.0 | 56/0.3 | 0.8 | 4.20 | 4.8 |
| 6.0 | 84/0.34 | 0.8 | 4.78 | 6.3 |
| 10 | 84/0.4 | 1.0 | 6.23 | 7.6 |
| 16 | 126/0.4 | 1.0 | 7.88 | 8.8 |
| 25 | 196/0.4 | 1.2 | 9.48 | 10.2 |
| 35 | 276/0.4 | 1.2 | 10.95 | 11.7 |
| 50 | 396/0.4 | 1.4 | 12.63 | 13.9 |
| 70 | 360/0.5 | 1.4 | 14.53 | 16.0 |
Standards & Compliance
Certified to recognised standards
Why Voltaris
What forty years of manufacturing gives you.
- 01
Own PVC compounding
Special resin produced in-house, in any colour, for consistent quality batch to batch.
- 02
OEM & private label
Many customers today started as private-brand buyers — we build to your spec and your label.
- 03
Flexible packaging
Reels in plastic or wood, coils, small bobbins, bulk or retail-ready packaging.
- 04
Export logistics
Direct shipping lanes from Shanghai and Ningbo ports to distributors worldwide.
Related Products
You may also need
Need expert advice or a custom spec?
Send us your gauge, quantity and application — we'll reply with pricing and lead time.
Request a cable quote
