H05V-R / H07V-R Single Core
Stranded rigid-conductor PVC single core to CE / VDE / BS.
Application
Where H05V-R / H07V-R Single Core is used
Fixed wiring where a class-2 stranded conductor is preferred over solid — switchboards, conduit runs and control gear, at 300/500 V (H05V-R) or 450/750 V (H07V-R).
- ✓Class-2 stranded copper conductor
- ✓PVC insulated
- ✓CE / VDE / BS standard
- ✓300/500 V and 450/750 V ratings
Part Numbers & Dimensions
Full technical reference
All figures are from our current production datasheet. Contact us for the signed PDF version for procurement.
H05V-R — 300/500 V
| Nominal Area (mm²) | Structure (mm) | Insulation Thickness (mm) | Nominal Diameter (mm) | Max Diameter (mm) |
|---|---|---|---|---|
| 0.5 | 7/0.3 | 0.6 | 2.12 | 2.6 |
| 0.75 | 7/0.37 | 0.6 | 2.33 | 2.8 |
| 1.0 | 7/0.43 | 0.6 | 2.50 | 3.0 |
H07V-R — 450/750 V
| Nominal Area (mm²) | Structure (mm) | Insulation Thickness (mm) | Nominal Diameter (mm) | Max Diameter (mm) |
|---|---|---|---|---|
| 1.5 | 19/0.32 | 0.7 | 3.00 | 3.5 |
| 2.5 | 19/0.41 | 0.8 | 3.62 | 4.2 |
| 4.0 | 19/0.52 | 0.8 | 4.20 | 4.8 |
| 6.0 | 19/0.64 | 0.8 | 4.78 | 6.3 |
| 10 | 49/0.52 | 1.0 | 6.23 | 7.6 |
| 16 | 49/0.64 | 1.0 | 7.88 | 8.8 |
| 25 | 98/0.58 | 1.2 | 9.48 | 11.02 |
| 35 | 133/0.58 | 1.2 | 10.95 | 11.7 |
| 50 | 189/0.58 | 1.4 | 12.63 | 13.9 |
